Control Valve
Description
This valve adopts a modular design with strong versatility and interchangeability, featuring a compact structure. It is equipped with a sleeve-guided plug with a balance piston. Using piston sealing rings made of different materials, it achieves pressure balance, making it suitable for high differential pressure applications and meeting user requirements.
Share:
Sleeve-guided plug with balanced piston, equipped with piston sealing rings of different materials.
Mainly used for two-phase flow control and ratio control, saving space and reducing cost.
The sleeve is connected to the valve body in a compression manner, effectively enhancing the valve’s sealing class and stability, while being exceptionally convenient for use and maintenance, significantly improving the overall performance of the control valve.
|
Type |
Three-Way Pressure Balanced Type |
|
Nominal Diameter |
DN25～DN250（1”～10”） |
|
Nominal Pressure |
PN16、25、40、64、100（150lb、300lb、600lb） |
|
Inherent Flow Characteristic |
Equal Percentage, Linear |
|
Inherent Rangeability |
50﹕1 |
|
Upper Bonnet Type |
Standard Type: Cast Steel: -20 to 200; Cast Stainless Steel: -40 to 200 |
|
Cooling Fin Type: Cast Steel: -29 to 425; Cast Stainless Steel: -40 to 450 |
|
|
Seat Leakage Class |
Class IV, V (Please confirm with the technical department), VI (Quick-opening shut-off type, soft-sealed) |
Send Us Your Project Requirements
And We'll Match You With The Best Product Solution.
YSM high-performance regulating valves, with a wide range of structural valve internals that cover various operating conditions in a one-stop solution, provide long-term stable and reliable operation, ensuring precise regulation and efficient operation of the system.
